Female Swivel Eye Bolt

SKU:
CODIPRO-FSEB
$123.47 - $604.81
$123.47 - $604.81

Description

The FE.SEB female swivel eye bolt is a single swivel ring. It is equipped with a self-orientation system that always guides it perfectly in the sling direction. It is composed of a GRADUP lifting ring which allows the hook to move parallel to the ring’s bearing surface when lifting at 90°. It is designed to perform lifts including load rotation and can be used for any lifting configuration (straigt lift, with angle, tilting, rotating).

The FE.SEB lifting ring is designed for use in a temperature range from -20°c to +200°c and carries various markings, including CE, WLL and tightening torque. It is manufactured in compliance with the REACH regulation and is also available as male version.

Extra Information

M8:
WLL (t) 5:1 - 0.40 / 4:1 - 0.50
M10:
WLL (t) 5:1 - 0.50 / 4:1 - 0.70
M12:
WLL (t) 5:1 - 0.80 / 4:1 - 0.90
M16:
WLL (t) 5:1 - 1.40 / 4:1 - 1.80
M20:
WLL (t) 5:1 - 2.00 / 4:1 - 2.70
M24:
WLL (t) 5:1 - 3.40 / 4:1 - 4.20
M30:
WLL (t) 5:1 - 5.50 / 4:1 - 6.30
M36:
WLL (t) 5:1 - 9.00 / 4:1 - 11.00
